3515
The TYM 3515 tractor, a member of the Series 2 compact tractors, offers a perfect blend of versatility and power. With its compact design and impressive 35 horsepower engine, this tractor is ready to tackle a wide range of tasks on and off the field.
TYM 3515 Compact Tractor: Versatility and Power Combined
The TYM 3515 tractor, a member of the Series 2 compact tractors, offers a perfect blend of versatility and power. With its compact design and impressive 35 horsepower engine, this tractor is ready to tackle a wide range of tasks on and off the field.
Perfect for Various Applications:
Whether you're involved in arable farming, construction, snow clearing, or landscaping, the TYM 3515 tractor is designed to excel in various applications. Its compact size allows you to navigate tight spaces and work efficiently in narrow areas between garden beds. From tilling and leveling the land to scattering soil and seed treatment, this tractor helps you achieve your agricultural goals. Additionally, the shorter variations of the TYM 3515 make it suitable for smaller greenhouse operations.
Powerful and Customizable:
The TYM 3515 tractor combines a 35 horsepower engine with a customizable transmission, tires, and implements, providing you with maximum control for handling any job. The tractor's high-torque engine ensures exceptional performance, while the customizable features allow you to optimize the tractor for specific tasks. Whether you need an HST or Synchro-Shuttle transmission, the TYM 3515 is equipped to meet your requirements.
Enhanced Operator Experience:
The TYM 3515 tractor is designed with the operator's comfort and convenience in mind. The ergonomic lever placement, suspension seat, and high visibility instrumental panel ensure that the operator can work comfortably and efficiently. With features like forward and reverse HST (3515H) and a high-capacity fuel tank, this tractor is built to keep you productive and energized throughout the day.
Reliable and Efficient:
TYM tractors are known for their reliability and efficiency, and the 3515 is no exception. With a naturally aspirated engine designed and manufactured by TYM, this tractor offers exceptional performance while remaining eco-friendly and fuel-efficient. You can rely on the 3515 to deliver power and reliability for all your agricultural needs.
Technical Excellence:
For those seeking detailed specifications, M&M Equipment in Winnsboro has a comprehensive list of technical details on the TYM 3515 tractor. From engine and powertrain information to hydraulic system specifications, you can access all the necessary information to make an informed decision based on your specific requirements.
Upgrade Your TYM Tractor:
To further enhance the capabilities of your TYM 3515 tractor, consider compatible options and accessories. From tire upgrades to other practical accessories, you can customize your tractor to suit your unique needs.
The TYM 3515 compact tractor offers versatility, power, and customization options to meet the demands of various applications. When you choose M&M Equipment in Winnsboro, LA, you not only get access to the TYM 3515 tractor at a great price but also benefit from our exceptional service and support. We are committed to ensuring that your TYM tractor meets and exceeds your expectations. Visit us today to experience the TYM 3515 difference at M&M Equipment.
Technical specifications
Not sure which tractor is right for you? Compare the specifications of each tractor model.
3515
3515R 3515H
ENGINE
Engine manufacturer TYM A1700N2 IDI TYM A1700N2 IDI
Type Natural Aspiration Natural Aspiration
Gross engine power 35 hp | 26.2 kW 35 hp | 26.2 kW
PTO power 30 hp | 22.5 kW 30 hp | 22.5 kW
Rated engine speed 2600 rpm 2600 rpm
No. of cylinders 3 3
Displacement 104.5 cu. in. 104.5 cu. in.
Air cleaner Dry Element Dry Element
Alternator 12V, 50A 12V, 50A
Fuel system IDI IDI
POWERTRAIN
Transmission type Synchromesh HST
No. of speeds F12xR12 3-Range
Max. traveling speed 14.4 mph 18.8 mph
Brakes Wet, Multi-disc Wet, Multi-disc
Steering Hydrostatic Hydrostatic
Clutch Dry Single Plate No
HYDRAULIC SYSTEM
Pump type Single Gear Pump Single Gear Pump
Implement flow 4.3 gpm 4.3 gpm
Steering flow 8 gpm 8 gpm
Total flow 12.3 gpm 12.3 gpm
Category, 3-point hitch I I
Hitch lift capacity 3306 lb 3306 lb
Hitch lift cap. (24” behind link ends) 2425 lb 2425 lb
Lift control type Position Position
# std. remote valves Optional (Max. 4) Optional (Max. 4)
PTO
PTO type Independent Independent
PTO control Wet, Multi-disc Wet, Multi-disc
PTO rear 560 rpm 560 rpm
CAPACITIES
Fuel tank 7.1 gal 7.1 gal
Coolant 5.28 qt 5.28 qt
Crankcase 4.5 qt 4.5 qt
Transmission/Hydraulics sys. 8.9 gal 9.8 gal
Front axle 1.7 qt 1.7 qt
DIMENSIONS & WEIGHTS
Overall length w/ 3-pt hitch 120.9 in. 120.9 in.
Overall width 56.3 in. 56.3 in.
Wheelbase 65.7 in. 65.7 in.
Height to top of ROPS 97.3 in. 97.3 in.
Min. ground clearance 14.4 in. 14.4 in.
Min. turn radius with brakes 7.51 in. 7.51 in.
Min. turn radius w/o brakes 8.5 ft. 8.5 ft.
Weight with ROPS 3183 lb 3163 lb
STANDARD TIRES
R1 Agricultural - Front 8-16 8-16
R1 Agricultural - Rear 12.4-24 12.4-24
R4 Industrial - Front 28x8.50-15 28x8.50-15
R4 Industrial - Rear 43x16.00-20 43x16.00-20
Upgrades for the Series 2, 3515
Complement the capabilities of your TYM tractor with compatible options and accessories.
Options
Tire R1 Agricultural Tires F 8.0-16 R 12.4-24
Tire R4 Industrial Tires F 28x8.50-15 R 43x16.00-20
